MS Elbow

Name: MS Elbow
Brand: JAYANT PIPE AND TUBES
Price: 150.0 INR
Availability: InStock

Price 150.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

MS Elbow Specification

Capacity
PN6 to PN64

Diameter
50 mm to 1200 mm

Standard
ANSI B16.9, ASME B16.9, DIN, JIS

Tensile Strength
350-600 MPa

Surface Treatment
Other

Grade
IS 1239, ASTM A234 WPB, A420 WPL6

Thickness
1.5 mm to 36 mm

Shape
Elbow (Curved)

Feature
High Strength, Leak Proof, Durable

Load Capacity
Up to 45 bar (varies with size and schedule)

Thread Type
Plain End, Beveled End (No Threads)

Finish
Smooth, Painted

Corrosion Resistant
Yes

Head Type
Round

Hardness
60-80 HRB

Material
Other

Tolerance
0.1 mm

Application
Oil & Gas, Water Supply, Power Plants, Chemical Industry, Construction

Service Life
Long Service Life, 20+ Years

Bend Angle
90, 45, Custom Angles Available

Weight
Varies as per size and thickness; typically 2 kg - 285 kg

Manufacturing Process
Hot Formed, Seamless or Welded

Pressure Rating
Class 150/300/600

End Type
Plain End, Beveled End

Connection Type
Butt Weld

Color
Black

Operating Temperature
-20C to 350C

MS Elbow About

MS Elbow (Mild Steel Elbow) is a durable pipe fitting designed to change the direction of fluid flow in piping systems. Manufactured from premium-grade mild steel, it offers excellent strength, pressure resistance, and long service life. Available in 45 and 90 angles with multiple diameters and wall thicknesses, MS elbows are widely used in plumbing, water supply, oil & gas, fire fighting, HVAC, chemical processing, and industrial pipeline applications. Their robust construction, precise dimensions, and smooth finish ensure easy installation, leak-free performance, and reliable operation in demanding environments.

Built for Strength and Longevity

Constructed from premium quality mild steel, our MS elbows deliver unmatched durability and feature a high tensile strength of 350-600 MPa. They are designed for a long service life, typically surpassing 20 years, and reliably perform under high pressure (Class 150/300/600) and demanding operational temperatures ranging from -20C to 350C.

Versatile Applications Across Industries

Our MS elbows support a wide range of industries, from oil & gas pipelines and chemical plants to water supply networks and construction projects. Their compatibility with several fitting standards and customizability in bend angles, sizes, and thicknesses make them ideal for diverse technical requirements.

Quality Manufacturing and Finishing

Each elbow is produced using advanced hot-formed methods, either seamless or welded, and finished with black paint or anti-rust oil for robust surface protection. With a smooth, painted finish and choice of plain or beveled ends, these elbows provide a leak-proof, corrosion-resistant solution suitable for tough environments.

FAQ's of MS Elbow:

Q: How are MS elbows with various bend angles manufactured?

A: MS elbows are produced using hot-forming processes that can yield seamless or welded elbows. Standard bend angles like 90 and 45 are readily available, while custom angles can be manufactured based on specific project requirements. The elbows undergo surface treatments such as black painting or anti-rust oil coating to enhance durability.

Q: What are the key benefits of using MS elbows in pipelines?

A: MS elbows offer numerous benefits, including high strength, excellent corrosion resistance, leak-proof connections due to butt weld ends, and a long operational lifespan exceeding 20 years. Their versatility in sizes, thicknesses, and bend angles makes them suitable for a wide variety of industrial applications.

Q: When should I use a beveled end versus a plain end on an MS elbow?

A: Beveled ends are typically chosen for applications requiring butt-welded joints, as they facilitate a stronger, leak-resistant weld. Plain ends may be desirable for certain installation methods or where further processing is needed. The choice depends on installation standards and pipeline requirements.

Q: Where are MS elbows commonly used?

A: MS elbows are widely employed in oil and gas industries, water supply lines, power generation plants, chemical processing systems, and construction projects. Their robust build and compliance with international standards make them a trusted choice for critical piping systems.

Q: What is the pressure rating and load capacity of these MS elbows?

A: These elbows are rated for pressure classes 150, 300, and 600, and can handle load capacities up to 45 bar, depending on the size and wall thickness of the fitting. Such ratings ensure reliable operation in high-pressure environments.

Q: How should MS elbows be maintained to maximize service life?

A: Routine inspection and preventive maintenance-including checking for external corrosion, verifying weld integrity, and reapplying surface coatings as needed-are recommended to maximize the over 20-year service life of MS elbows. Adhering to industry standards for installation and operation also ensures longevity.
